Cylindrical Grinding
Solutions for internal, external, and face grinding. Maximum precision on circular geometries.
Features and Capabilities:
-
External, internal and eccentric geometry (XC profiles) cylindrical grinding,
-
Turning, plongee, multi-plongee, and shoulder operations, as well as combined turning + shoulder and plongee + shoulder operations…
-
For straight turning, conical turning, and concave or convex rolling.
-
You can define up to 5 machining stages with specific conditions: GAP (approach), roughing, finishing, superfinishing, and ultra-finishing.
-
Option for automatic GAP management, before roughing, calculating the workpiece dimensions using acoustic signals.
-
Possibility of sparks or final passes in the air to achieve an optimal surface finish (mirror finish).
-
Option to easily integrate a workpiece measurement probe into the cycle.
-
Interactive guide to selecting the appropriate grinding wheel and performing stone dressing operations.
-
Grinding wheel definition page and magazine option with up to four positions.
-
Simple definition of the grinding wheel's geometry or shape.
Available Cycles:
-
Plongee: standard external immersion cycle.
-
Plongee & Shoulder: combined external immersion and shoulder cycle.
-
Reciprocating: external grinding cycle with longitudinal movement.
-
Reciprocating & Shoulder: combined external longitudinal and shoulder cycle.
-
Conical Reciprocating: external reciprocating cycle adapted for conical geometries.
-
Rolling: grinding cycle for external concave and convex shapes.
-
Multiplongee: external multiple immersion cycle.
-
Multiplongee & Shoulder: combined external multiple immersion and shoulder cycle.
-
Plongee XC: external immersion cycle for grinding non-circular profiles.
-
Reciprocating XC: external longitudinal cycle for grinding non-circular profiles.
-
Shoulder: specific external cycle for grinding shoulders or faces.
-
Internal Plongee: internal immersion cycle.
-
Internal Plongee & Shoulder: combined internal immersion and shoulder cycle.
-
Internal Reciprocating: internal grinding cycle with longitudinal movement.
-
Internal Shoulder: specific internal cycle for grinding shoulders or faces.
-
Modelling or dressing cycle: enables the dressing or modelling of the grinding wheels available on the machine to keep the correct profile and ensure proper grinding.
-
Dresser Offset: process for capturing the dresser-wheel zero.
-
Workpiece Offset: process for capturing the workpiece-wheel zero.
